Air Design - Volt 5
The Volt 5 is the fifth of its name and... How to put it? Well, it's the second generation of the first 2-liner EN-C. In other words, it's the first 2-liner EN-C to benefit from a second generation. Or, put differently, it's now the fifth generation of Volt but the second generation of 2-liners. Or...Anyway! Always a step ahead. Take it to the next level with the Volt 5. A true 2-liner EN-C.SPECIAL PRICE: LOG IN WITH YOUR CUSTOMER ACCOUNT
Please select all options
This product is available on supplier order. Delivery time: 1 to 4 weeks.
Ref. AIRDESIGNVOLT5
Detailed description
"The Rid'Air team's opinion: The Volt 5 is the worthy successor to the market's first 2-liner EN-C. It further improves performance, especially upwind, while remaining incredibly easy to launch. It's the ideal #speedmachine for taking your XC flying to the next level without the stress of a competition wing."
Volt 5 #speedmachine: The Evolution of the Accessible 2-Liner
The Volt 5 marks a new milestone for AirDesign: it's the second generation of the first 2-liner ever certified in the EN-C category. This wing merges the legendary accessibility of the Volt range with cutting-edge technologies from high-performance wings. Agile, smooth to control, and fast, it has been optimized to deliver exceptional efficiency in active air masses and improved glide at high speeds.
The construction incorporates new Nose Guard Patches, reinforcements on the leading edge that increase robustness against abrasion. The use of Dominico DOKDO-10DSF double-coated fabric for the top and bottom surfaces ensures record lightness without sacrificing durability. Nitinol rods along the entire chord not only ensure an impeccable profile in accelerated flight but also allow for compact folding without risk of deformation.
Rear riser control (B-risers) is intuitive and efficient, allowing precise angle of attack control during transitions. Whether you're a performance hike & fly enthusiast or a cross-country mile hunter in the flats, the Volt 5 offers the immense pleasure of 2-liner flying with passive safety that remains exemplary for its class.
The Volt 5 is an EN-C category wing using 2-liner technology. It is aimed at regular pilots (approx. 100h/year) looking for a high-performance wing for cross-country flying while benefiting from the lightness of a Superlight structure.
Technical Specifications
| Size | XXS | XS | S | M | ML | L |
|---|---|---|---|---|---|---|
| Flat surface (m²) | 19.97 | 21.40 | 22.85 | 24.59 | 26.33 | 28.07 |
| Projected surface (m²) | 17.09 | 18.33 | 19.56 | 21.05 | 22.54 | 24.03 |
| Flat aspect ratio | 6.45 | |||||
| Number of cells | 57 | |||||
| Weight (12mm risers) | 3.39 kg | 3.64 kg | 3.72 kg | 3.83 kg | 4.10 kg | 4.37 kg |
| Weight (SL risers) | 3.28 kg | 3.53 kg | 3.61 kg | 3.72 kg | 3.99 kg | 4.26 kg |
| PTV (kg) | 60-73 | 68-82 | 78-92 | 88-103 | 99-115 | 110-128 |
| EN Certification | C | |||||
Materials
- Top / Bottom surface: Dominico DOKDO-10DSF double coated 25 g/m²
- Ribs: Dominico DOKDO-204432FM / Skytex 27 hard
- Lines: Edelrid 8001/U (Unsheathed Aramid)
- Rods: Nitinol
- Risers: Aramid 12mm (or Dyneema Superlight optional)
